Multihead Column Profiling/Copying Machine (Four Heads)
Product name : Multihead Column Profiling/Copying Machine (Four Heads)
Item : JNPM-1000
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:

JNPM-1000 Multihead Column Profiling/Copying Machine (Four Heads)

Features:

1. Optical fiber sensing system makes it for easy and precise operation;

2. Different kinds of wood templates/models are available;

3. Pneumatic fastening system makes it easy to load/unload workpieces and avoid vibrations;

4. Cut four workpieces (at most) at the same time;

5. Capable of making balusters, balls, columns, column bases/caps, vases, planters, pots, stools in  different materials (wood, marble, granite, basalt, etc.);;

6. Labor-saving and efficient;

7. Recyclable water use.

Technical data

Model

JNPM-1000

Operation mode

Optical fiber sensing system

Dimension (L*W*H)

5200*2200*2500mm

Cutting height

1200mm

Max. cutting diameter

1000mm

Max. number of workpieces processed

4pcs

Number of blades

4pcs

Blade diameter

400-600mm

Operating voltage/frequency

380V/3PH/50Hz

Total power

40Kw

Total weight

7800Kgs

Water consumption

5m³/h

Packing

Seaworthy packing, wrapped by waterproof plastic films and air bubbles
